Technical Specifications
The key figures for the FrenschPress. What each port does is described under Connections and Interfaces.
Device
| Feature | Value |
|---|---|
| Dimensions | 115 × 80 × 38 mm |
| Weight | 0.3 kg |
| Housing | Aluminium, matt black, with TPU bumper |
| Encoder | 1 × 32 mm, aluminium |
| Buttons | 3 × mechanical with RGB LED |
| Processor | 240 MHz dual-core |
| Memory | 8 MB flash, 8 MB PSRAM |
Connectors and wireless
| Feature | Value |
|---|---|
| Connectors | 2 × USB-C (USB 1, USB 2), 1 × RJ45 |
| Network | Ethernet, DHCP or static IP |
| Wireless | Wi-Fi 2.4 GHz (optional) |
| Protocols | MIDI (USB and RTP-MIDI), OSC, HTTP, TCP, Art-Net, sACN, MIDI and Art-Net timecode |
Power and environment
| Feature | Value |
|---|---|
| Supply | 5 V ⎓ via USB-C |
| Recommended power supply | 5 V / 1 A |
| Operating temperature | 0–50 °C |
Power
The FrenschPress is powered through either of its two USB-C ports, from a computer or from a power supply. It makes no difference which port you use. For standalone operation on a network we recommend a stable power supply rated 5 V / 1 A.
Accessories on USB 2
The FrenschPress supplies no power to accessories. A Stream Deck or LTC dongle on USB 2 therefore always needs a powered USB hub.
For CE, RoHS and disposal, see Conformity & disposal.
